Load up the van, hit the road, climb a mountain, hammer it back down, huck the gap, throw the bike back in the van, and drive to the bike park for laps on laps. Hell, you could even roll up to the start line of the world’s wildest races. The Nomad’s forte is being ready and willing to go wherever, whenever. All it needs is a rider willing to press send.
A bigger wheel up front, optimized geometry for good times, Glovebox storage, and the biggest-hitting VPP™ suspension come together to create a bike that inspires confidence in going wherever, whenever, and tackling whatever’s in your way.
VPP™ suspension strikes the ideal balance between pedaling efficiency and bump-chomping prowess. The Nomad excels at absorbing the biggest hits, allowing riders to charge harder and with greater confidence in the toughest terrain. Plus, its efficiency means reaching the highest, best trails is never a chore.
Frame | |
---|---|
Frame | Carbon C MX 170mm Travel VPP™ |
Weight | 35.92lbs / 16.29 kg |
Wheel Size | MX |
Suspension | |
Fork | RockShox Zeb Base, 170mm |
Shock | FOX Float X Performance, 230x65 |
Drivetrain | |
Bottom Bracket | SRAM DUB 73mm MTB Wide BB |
Cassette | SRAM XS 1270 Eagle T-Type, 10-52t |
Chain | SRAM 70 Eagle T-Type, Flattop, 12spd |
Chainguide | E.13 TRS Race SL, ISCG05 |
Crankset | SRAM 70 Eagle DUB T-Type Crankset, 32t |
Rear Derailleur | SRAM 70 Eagle T-Type, 12spd |
Right Shifter | SRAM 90 Eagle T-Type, 12spd |
Brakes | |
Front Brakes | SRAM DB8 |
Front Rotor | SRAM Centerline, 200mm |
Rear Rotor | SRAM Centerline, 200mm |
Cockpit | |
Grips / Bar Tape | Santa Cruz Bicycles House Grips |
Handlebars | Burgtec Alloy Bar |
Headset | Cane Creek 10 IS Integrated Headset |
Saddle | SDG Bel-Air V3, Steel |
Seatpost | SDG Tellis Dropper, 31.6 |
Stem | OneUp Enduro Stem, 42mm |
Wheels | |
Front Rim | Reserve 30|TR AL |
Front Hub | SRAM MTH 716, 15x110, 6-Bolt, 32h |
Front Tire | Maxxis Assegai 29"x2.5", 3C MaxxGrip, EXO+ |
Rear Rim | Reserve 30|HD AL |
Rear Hub | SRAM MTH 746, 12x148, HG, 6-Bolt, 32h |
Rear Tire | Maxxis Minion DHR II 27.5"x2.4", 3C MaxxTerra, Double Down |
Specs | |
Bottom Bracket Shell | 73mm Threaded |
Rear Brake Mount | 200 PM |
Shock Length | 230mm |
Fork Compatibility | 170-180mm |
Fork Offset | 44mm |
Front Derailleur Mount | No compatibility |
Headset | Integrated (IS41/52) |
Max Tire Clearance | 2.5" |
Seat Clamp Diameter | 36.4mm |
Seat Post Diameter | 31.6mm |
Shock Bushing Size Front | 30x8 |
Shock Bushing Size Rear | 30x8 |
Shock Stroke | 65mm |
Suspension System | VPP |
Water Bottle Mounts | 1 |
